C Connectors Standard
Heavy-duty C connectors designed to provide secure and low-resistance connections between conductors in earthing systems, substations, power distribution networks, and lightning protection installations.
Become a DISTRIBUTORS
| Material | Brass/Copper Alloy/Silicone Bronze |
|---|---|
| Finish | Natural or Tin Plated |
Technical Specifications
| CAT NO. | A | B | C |
|---|---|---|---|
| ZXCC25 | 21.4 | 13 | 17 |
| ZXCC35 | 26.6 | 15.6 | 21 |
| ZXCC70 | 34.2 | 21 | 28 |
| ZXCC95 | 41 | 26 | 29.4 |
| ZXCC120 | 55 | 28 | 30 |
| CAT NO. | A | B | C |
|---|---|---|---|
| ZCD35 | 30 | 14.3 | 19 |
| ZCD70 | 39 | 19 | 19 |
| ZCD120 | 52 | 24 | 22 |
| ZCD240 | 74 | 34.4 | 28 |
| CAT NO. | A | B | C |
|---|---|---|---|
| ZCE35/70 | A | 18.3 | 19 |
| ZCE70/120 | 50 | 23.7 | 19 |
| ZCE70/240 | 62 | 30.9 | 22 |
| ZCE120/240 | 68 | 33.9 | 28 |
| CAT NO. | A | B | C | E |
|---|---|---|---|---|
| ZEC1.5 | 53 | 23 | 19 | 2 |
| ZEC2.5 | 53 | 23 | 19 | 2.5 |
| ZEC4 | 53 | 23 | 19 | 3 |
| ZEC6 | 53 | 23 | 19 | 3.5 |
| ZEC10 | 53 | 23 | 19 | 4.5 |
| ZEC16 | 53 | 23 | 19 | 5.5 |
| ZEC25 | 53 | 23 | 19 | 7.5 |
| ZEC35 | 53 | 23 | 19 | 8.5 |
| ZEC50 | 53 | 23 | 19 | 9.5 |
| ZEC70 | 53 | 23 | 19 | 11.5 |
| ZEC95 | 53 | 23 | 19 | 13.5 |
| ZEC120 | 53 | 23 | 19 | 15.5 |
