Roller Ball Lock Type Steel Cable Ties Coated
Roller Ball Lock Type Steel Cable Ties Coated - Image 2
Roller Ball Lock Type Steel Cable Ties Coated - Image 3

Roller Ball Lock Type Steel Cable Ties Coated

Category:

Premium coated stainless steel cable ties with a roller ball locking system, designed for secure cable management. Offering excellent corrosion resistance, high tensile strength, and long-lasting performance for industrial, marine, telecom, and power distribution applications.

PRODUCT INQUIRY

Become a DISTRIBUTORS

    Material 304 & 316 Grade Non Magnetic Stainless Steel
    Finish Epoxy Coated
    Temperature -60˚C To +150˚C

    Technical Specifications

    PART CODE AS PER STAINLESS STEEL GRADE WIDTH LENGTH THICKNESS MAX. LOOP DIAMETER MAX. LOOP TENSILE STRENGTH PACKAGE QUANTITY
    SS304 SS316 INCH MM INCH MM INCH MM INCH MM N LBS PCS
    EBC14-100 EBC16-100 0.18 4.6 4 100 0.01 0.25 0.94 24
    EBC14-127 EBC16-127 0.18 4.6 5 127 0.01 0.25 1.02 26
    EBC14-150 EBC16-150 0.18 4.6 6 150 0.01 0.25 1.57 40
    EBC14-200 EBC16-200 0.18 4.6 8 200 0.01 0.25 2.2 56
    EBC14-260 EBC16-260 0.18 4.6 10 260 0.01 0.25 2.95 75
    EBC14-300 EBC16-300 0.18 4.6 12 300 0.01 0.25 3.46 88
    EBC14-360 EBC16-360 0.18 4.6 14 360 0.01 0.25 4.21 107
    EBC14-400 EBC16-400 0.18 4.6 16 400 0.01 0.25 4.53 115 465 105 100/BAG
    EBC14-450 EBC16-450 0.18 4.6 18 450 0.01 0.25 5.31 135
    EBC14-520 EBC16-520 0.18 4.6 20 520 0.01 0.25 6.22 158
    EBC14-550 EBC16-550 0.18 4.6 22 550 0.01 0.25 6.38 162
    EBC14-620 EBC16-620 0.18 4.6 24 620 0.01 0.25 7.48 190
    EBC14-680 EBC16-680 0.18 4.6 27 680 0.01 0.25 7.87 200
    EBC14-840 EBC16-840 0.18 4.6 33 840 0.01 0.25 10.24 260
    EBC14-1000 EBC16-1000 0.18 4.6 39 1000 0.01 0.25 12.24 311
    PART CODE AS PER STAINLESS STEEL GRADE WIDTH LENGTH THICKNESS MAX. LOOP DIAMETER MAX. LOOP TENSILE STRENGTH PACKAGE QUANTITY
    SS304 SS316 INCH MM INCH MM INCH MM INCH MM N LBS PCS
    EBC24-150 EBC26-150 0.31 7.9 6 150 0.01 0.25 1.57 40
    EBC24-200 EBC26-200 0.31 7.9 8 200 0.01 0.25 2.2 56
    EBC24-260 EBC26-260 0.31 7.9 10 260 0.01 0.25 2.95 75
    EBC24-300 EBC26-300 0.31 7.9 12 300 0.01 0.25 3.46 88
    EBC24-360 EBC26-360 0.31 7.9 14 360 0.01 0.25 4.21 107
    EBC24-400 EBC26-400 0.31 7.9 16 400 0.01 0.25 4.53 115
    EBC24-450 EBC26-450 0.31 7.9 18 450 0.01 0.25 5.31 135 1200 270 100/BAG
    EBC24-520 EBC26-520 0.31 7.9 20 520 0.01 0.25 6.22 158
    EBC24-550 EBC26-550 0.31 7.9 22 550 0.01 0.25 6.38 162
    EBC24-620 EBC26-620 0.31 7.9 24 620 0.01 0.25 7.48 190
    EBC24-680 EBC26-680 0.31 7.9 27 680 0.01 0.25 7.87 200
    EBC24-840 EBC26-840 0.31 7.9 33 840 0.01 0.25 10.24 260
    EBC24-1000 EBC26-1000 0.31 7.9 39 1000 0.01 0.25 12.24 311
    PART CODE AS PER STAINLESS STEEL GRADE WIDTH LENGTH THICKNESS MAX. LOOP DIAMETER MAX. LOOP TENSILE STRENGTH PACKAGE QUANTITY
    SS304 SS316 INCH MM INCH MM INCH MM INCH MM N LBS PCS
    EBC34-200 EBC36-200 0.5 12 8 200 0.01 0.3 2.2 56
    EBC34-260 EBC36-260 0.5 12 10 260 0.01 0.3 2.95 75
    EBC34-300 EBC36-300 0.5 12 12 300 0.01 0.3 3.46 88
    EBC34-360 EBC36-360 0.5 12 14 360 0.01 0.3 4.21 107
    EBC34-400 EBC36-400 0.5 12 16 400 0.01 0.3 4.53 115
    EBC34-450 EBC36-450 0.5 12 18 450 0.01 0.3 5.31 135 2000 450 100/BAG
    EBC34-520 EBC36-520 0.5 12 20 520 0.01 0.3 6.22 158
    EBC34-550 EBC36-550 0.5 12 22 550 0.01 0.3 6.38 162
    EBC34-620 EBC36-620 0.5 12 24 620 0.01 0.3 7.48 190
    EBC34-680 EBC36-680 0.5 12 27 680 0.01 0.3 7.87 200
    EBC34-840 EBC36-840 0.5 12 33 840 0.01 0.3 10.24 260
    EBC34-1000 EBC36-1000 0.5 12 39 1000 0.01 0.3 12.24 311
