Copper Bonded Earth Rod
High-strength copper bonded earth rods designed to provide low-resistance grounding and long-term corrosion protection for electrical substations, power distribution systems, telecom networks, renewable energy projects, and industrial earthing applications.
Become a DISTRIBUTORS
| Material | Brass/Copper Alloy/Silicone Bronze |
|---|---|
| Finish | Natural or Tin Plated |
Technical Specifications
| E-CODE | ROD DIA. MM | TOTAL LENGTH | THREAD DIA |
|---|---|---|---|
| ZBR-012 | 12.5 | 1200 | 9/16″ |
| ZBR-014 | 12.5 | 1400 | 9/16″ |
| ZBR-015 | 12.5 | 1500 | 9/16″ |
| ZBR-018 | 12.5 | 1800 | 9/16″ |
| ZBR-024 | 12.5 | 2400 | 9/16″ |
| ZBR-030 | 12.5 | 3000 | 9/16″ |
| ZBR-112 | 14.2 | 1200 | 5/8″ |
| ZBR-115 | 14.2 | 1500 | 5/8″ |
| ZBR-118 | 14.2 | 1800 | 5/8″ |
| ZBR-120 | 14.2 | 2000 | 5/8″ |
| ZBR-124 | 14.2 | 2400 | 5/8″ |
| ZBR-130 | 14.2 | 3000 | 5/8″ |
| ZBR-212 | 17.2 | 1200 | 3/4″ |
| ZBR-215 | 17.2 | 1500 | 3/4″ |
| ZBR-218 | 17.2 | 1800 | 3/4″ |
| ZBR-224 | 17.2 | 2400 | 3/4″ |
| ZBR-230 | 17.2 | 3000 | 3/4″ |
| E-CODE | ROD DIA. MM |
|---|---|
| ZBC0916 | 9/16″ |
| ZBC058 | 5/8″ |
| ZBC0034 | 3/4″ |
| E-CODE | ROD DIA. MM |
|---|---|
| ZDB-0916 | 9/16″ |
| ZDB-0058 | 5/8″ |
| ZDB-0034 | 3/4″ |
