Stop Plug
Stop Plug is designed to securely seal unused cable entry holes in enclosures, junction boxes, control panels, and electrical equipment. It provides a reliable dust-tight and watertight seal, helping maintain enclosure integrity and protection against moisture, dust, and contaminants. Ideal for industrial, commercial, marine, and hazardous-area installations
Become a DISTRIBUTORS
| Material | Brass |
|---|---|
| Finish | Brass / Nickel |
| Type of Cable | Armoured & Unarmoured |
Technical Specifications
| ET THREAD SIZE | A/C | A/F | ‘T’ | ‘L’ | ‘A’ | |
|---|---|---|---|---|---|---|
| ZBSP 3/4″ET | 26 | 22 | 3 | 10 | 3/4″ET | J 5.5 |
| ZBSP 1″ ET | 32 | 28 | 3 | 10 | 1″ET | 2J |
| ZBSP 1-1/4″ ET | 42 | 36 | 4 | 10 | 1-1/4″ET | 27.8 |
| ZBSP 1-1/2″ ET | 49 | 42 | 4 | 10 | 1-1/2″ET | 33.5 |
| ZBSP 2″ ET | 63 | 54 | 4 | 12 | 2″ET | 45 |
| ZBSP 2-1/4″ ET | 71 | 61 | 4 | 12 | 2-1/4″ET | 52 |
| ZBSP 2-1/2″ ET | 79 | 68 | 5 | 12 | 2-1/2″ET | 57.5 |
| ZBSP 2-3/4″ ET | 87 | 75 | 5 | 12 | 2-3/4″ET | 64 |
| ZBSP 3″ ET | 93 | 80 | 5 | 12 | 3″ET | 69 |
| ZBSP 3-1/4″ ET | 101 | 87 | 6 | 12 | 3-1/4″ET | 76 |
| ZBSP 3-1/2″ET | 109 | 94 | 6 | 12 | 3-1/2″ET | 82 |
| M THREAD SIZE | A/C | A/F | ‘T’ | ‘L’ | ‘A’ | |
|---|---|---|---|---|---|---|
| ZBSP M20 | 28 | 24 | 3 | 10 | M20 | 1ó.5 |
| ZBSP M25 | 34 | 29 | 3 | 10 | M25 | 21 |
| ZBSP M32 | 42 | 36 | 4 | 10 | M32 | 28 |
| ZBSP M40 | 51 | 44 | 4 | 10 | M40 | 35.5 |
| ZBSP M50 | 63 | 54 | 4 | 12 | M50 | 45 |
| ZBSP M63 | 79 | 68 | 5 | 12 | M63 | 57.5 |
| ZBSP M75 | 93 | 80 | 5 | 12 | M75 | 69 |
| ZBSP M90 | 110 | 95 | 6 | 12 | M90 | 83 |
