Copper Tube Crimping Lugs One Hole Din Standard 46235 90 Degree
90 degree DIN standard copper lugs provide secure cable termination and optimized cable management in compact electrical installations
Become a DISTRIBUTORS
| Material | High Conductor Aluminium 99.9% Pure |
|---|---|
| Finish | Tin Electro Plated and Annealed |
| Type of Cable | Stranded & Flexible |
Technical Specifications
| CAT. NO | CABLE mm2 |
STUD SIZE | BARREL ID | PALM WIDTH | BARREL LENGTH | PAD LENGTH |
|---|---|---|---|---|---|---|
| E | A | D | B | P | ||
| ZDIN65F | 6 | 5.3 | 3.8 | 8.5 | 10 | 15.0 |
| ZDIN66F | 6 | 6.4 | 3.8 | 8.5 | 10 | 18.5 |
| ZDIN105F | 10 | 5.3 | 4.5 | 9.0 | 10 | 15.0 |
| ZDIN106F | 10 | 6.4 | 4.5 | 9.0 | 10 | 18.5 |
| ZDIN166F | 16 | 6.4 | 5.5 | 13.0 | 20 | 18.5 |
| ZDIN168F | 16 | 8.4 | 5.5 | 13.0 | 20 | 23.0 |
| ZDIN1610F | 16 | 10.5 | 5.5 | 17.0 | 20 | 27.0 |
| ZDIN256F | 25 | 6.4 | 7 | 14.0 | 20 | 18.5 |
| ZDIN258F | 25 | 8.4 | 7 | 16.0 | 20 | 23.0 |
| ZDIN2510F | 25 | 10.5 | 7 | 17.0 | 20 | 27.0 |
| ZDIN2512F | 25 | 13.0 | 7 | 19.0 | 20 | 29.0 |
| ZDIN358F | 35 | 8.4 | 8.2 | 17.0 | 20 | 23.0 |
| ZDIN3510F | 35 | 10.5 | 8.2 | 19.0 | 20 | 27.0 |
| ZDIN3512F | 35 | 13.0 | 8.2 | 21.0 | 20 | 29.0 |
| ZDIN508F | 50 | 8.4 | 10 | 20.0 | 28 | 23.0 |
| ZDIN5010F | 50 | 10.5 | 10 | 22.0 | 28 | 27.0 |
| ZDIN5012F | 50 | 13.0 | 10 | 24.0 | 28 | 29.0 |
| ZDIN5016F | 50 | 17.0 | 10 | 28.0 | 28 | 35.0 |
| ZDIN708F | 70 | 8.4 | 11.5 | 24.0 | 28 | 23.0 |
| ZDIN7010F | 70 | 10.5 | 11.5 | 24.0 | 28 | 27.0 |
| ZDIN7012F | 70 | 13.0 | 11.5 | 24.0 | 28 | 29.0 |
| ZDIN7016F | 70 | 17.0 | 11.5 | 30.0 | 28 | 35.0 |
| ZDIN9510F | 95 | 10.5 | 13.5 | 28.0 | 35 | 27.0 |
| ZDIN9512F | 95 | 13.0 | 13.5 | 28.0 | 35 | 29.0 |
| ZDIN9516F | 95 | 17.0 | 13.5 | 32.0 | 35 | 35.0 |
| ZDIN12010F | 120 | 10.5 | 15.5 | 32.0 | 35 | 27.0 |
| ZDIN12012F | 120 | 13.0 | 15.5 | 32.0 | 35 | 29.0 |
| ZDIN12016F | 120 | 17 | 15.5 | 32.0 | 35 | 35.0 |
| ZDIN12020F | 120 | 21 | 15.5 | 38.0 | 35 | 42.0 |
| ZDIN15010F | 150 | 10.5 | 17 | 34.0 | 35 | 27.0 |
| ZDIN15012F | 150 | 13 | 17 | 34.0 | 35 | 29.0 |
| ZDIN15016F | 150 | 17 | 17 | 34.0 | 35 | 35.0 |
| ZDIN15020F | 150 | 21 | 17 | 40.0 | 35 | 42.0 |
| ZDIN18510F | 185 | 10.5 | 19 | 37.0 | 40 | 27.0 |
| ZDIN18512F | 185 | 13 | 19 | 37.0 | 40 | 29.0 |
| ZDIN18516F | 185 | 17 | 19 | 37.0 | 40 | 35.0 |
| ZDIN18520F | 185 | 21 | 19 | 40.0 | 40 | 42.0 |
| ZDIN24012F | 240 | 13 | 21.5 | 42.0 | 40 | 29.0 |
| ZDIN24016F | 240 | 17 | 21.5 | 42.0 | 40 | 35.0 |
| ZDIN24020F | 240 | 21 | 21.5 | 45.0 | 40 | 42.0 |
| ZDIN30016F | 300 | 17 | 24.5 | 48.0 | 50 | 35.0 |
| ZDIN30020F | 300 | 21 | 24.5 | 48.0 | 50 | 42.0 |
| ZDIN40016F | 400 | 17 | 27.5 | 55.0 | 70 | 41.0 |
| ZDIN40020F | 400 | 21 | 27.5 | 55.0 | 70 | 45.0 |
| ZDIN50020F | 500 | 21 | 31 | 60.0 | 70 | 45.0 |
| ZDIN62520F | 625 | 21 | 34.5 | 60.0 | 80 | 45.0 |
