Copper Tube Crimping Through Connectors Short Barrel
Short barrel copper through connectors designed for compact, secure, and efficient cable joining in industrial wiring and electrical distribution applications
Become a DISTRIBUTORS
| Material | High Conductor Aluminium 99.9% Pure |
|---|---|
| Finish | Tin Electro Plated and Annealed |
| Type of Cable | Stranded & Flexible |
Technical Specifications
| CAT. NO | CABLE SIZE AWG |
COLOR CODE | BARREL ID | TOTAL LENGTH |
|---|---|---|---|---|
| A | J | |||
| SC8 | 8 AWG | RED | 0.190 | 1.250 |
| SC6 | 6 AWG | BLUE | 0.232 | 1.750 |
| SC4 | 4 AWG | GREY | 0.280 | 1.750 |
| SC3 | 3 AWG | WHITE | 0.310 | 1.750 |
| SC2 | 2 AWG | BROWN | 0.336 | 1.870 |
| SC1 | 1 AWG | GREEN | 0.360 | 1.870 |
| SC10 | 1/0 AWG | PINK | 0.400 | 1.870 |
| SC20 | 2/0 AWG | BLACK | 0.460 | 1.900 |
| SC30 | 3/0 AWG | ORANGE | 0.510 | 2.100 |
| SC40 | 4/0 AWG | PURPLE | 0.560 | 2.100 |
| SC250 | 250 Kcmil | YELLOW | 0.630 | 2.250 |
| SC300 | 300 Kcmil | WHITE | 0.675 | 2.250 |
| SC350 | 350 Kcmil | RED | 0.720 | 2.250 |
| SC400 | 400 Kcmil | BLUE | 0.780 | 2.500 |
| SC500 | 500 Kcmil | BROWN | 0.860 | 2.870 |
| SC600 | 600 Kcmil | GREEN | 0.920 | 3.120 |
| SC750 | 750 Kcmil | BLACK | 1.056 | 3.465 |
